Precision Engineered Zirconia Ceramic Components Ceramic Bead Mill High Purity

Brand Name : YH

Certification : ISO

Place of Origin : CHINA

MOQ : 10

Price : Negotiated

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 10000pcs per month

Delivery Time : 10-30days

Packaging Details : by carton

Density : 6.0 g/cm³

Manufacturing Process : Injection molding, pressing, or milling

Material : Zirconia (Zirconium Dioxide)

Surface Finish : Polished or machined

Electrical Resistivity : 10^10 - 10^14 Ω·cm

Operating Temperature : Up to 2400°C

Hardness : 8.5 Mohs

Fracture Toughness : 7-10 MPa·m^0.5

Thermal Conductivity : 2-3 W/m·K

Flexural Strength : 900-1200 MPa

Applications : Dental implants, cutting tools, wear-resistant parts

Porosity : Typically <0.1%

Chemical Resistance : Excellent against acids and alkalis

Coefficient Of Thermal Expansion : 10.5 x 10^-6 /°C

Contact Now

Precision Engineered High Performance Bead Mill Zirconia Ceramic Component Ceramic Parts

Yttria Stabilized Zirconia (YSZ) Ceramic Component Part:

Yttria Stabilized Zirconia (YSZ) Ceramic Special-Shaped Parts: Ultimate Wear Resistance for Mechanical Transmission.

Engineered with high-purity YSZ material and precision-machined to custom profiles, these components redefine durability

in high-friction mechanical transmission systems, outperforming traditional metal parts by 5-10 times in wear resistance.

Ideal for custom-shaped bearing sleeves, gear inserts, and shaft collars in heavy-duty industrial machinery,

they withstand high-speed rotation, heavy loads, and continuous friction without abrasion or deformation.

By eliminating metal debris contamination and reducing wear-induced failures, YSZ ceramic part extend

he service life of transmission systems, lower maintenance costs, and ensure stable operation for critical industrial equipment.

Why Zirconia (YSZ) is the Superior Choice

When processing hard or high-purity materials, jar material wear can contaminate samples and skew

analytical data. Stainless steel introduces metallic ions, while alumina wears relatively quickly.

Yttria-Stabilized Zirconia solves these problems: it offers extreme hardness, outstanding chemical stability,

and is the ideal choice for achieving "true" grinding results.

Precision Engineered Zirconia Ceramic Components Ceramic Bead Mill High Purity

Technical Specifications

Composition:Yttria-Stabilized Zirconia (Y-TZP)Density: ≥ 6.0 g/cm³
Hardness (HV): ≥ 1250
Flexural Strength: ≥ 1000 MPa
Fracture Toughness: 8 - 11 MPa·m¹/²
Max. Service Temperature: ≥ 800 °C
Thermal Expansion Coefficient: ~10.5 × 10⁻⁶/K
Corrosion Resistance:Excellent ( Resists acids/alkalis)Biocompatibility:Excellent
Electrical Insulation:Good Insulator


Application

1) Industrial Pumps, Valves & Fluid Handling: Ceramic plungers, seal rings, valve cores, valve seats, nozzles
2) Precision Machinery & Automation: Guides, bearings, fixtures, measuring instrument parts, textile ceramics
3) Electronics & Semiconductors: Insulators, chip carriers, vacuum chucks.
4) Consumer Goods & Tools: High-quality knives and scissors, watch cases, decorative parts

Basic Physical & Mechanical Properties

			Zirconia Ceramic Properties

			Item

			Unit

			Typical Values

			Physical Properties

			Color

			Customized

			Density

			g/cm3

			6.00

			Zirconia Content

			%

			94.4

			Gas Permeability

			0

			Water Absorption

			0

			Crystal Size

			um

			0.5

			Mechanical Properties

			Rockwell Hardness(45N)

			R45N

			78

			Modulus of Elasticity (20°C)

			Gpa

			>200

			Compressive Strength (20°C)

			Mpa

			2000

			Flexural Strength (20°C)

			 Mpa

			800

			Thermal Properties

			Thermal Expansion Coefficient

			 10-6/°C

			9.6

			Thermal Shock Resistance

			T°C

			250

			Thermal Conductivity (20°C-400°C)

			W/m.K

			2.5

Precision Engineered Zirconia Ceramic Components Ceramic Bead Mill High Purity

Our Technical Expertise: The Reason to Choose Us
Feature :Premium Material & Precision Manufacturing

1:High-Purity Zirconia Base Material:

We use high-purity zirconia (ZrO₂) powder, stabilized with additives like yttrium oxide (Y₂O₃)

to obtain a stable tetragonal crystal phase at room temperature.This phase transformation

toughening mechanism is the cornerstone of our product's high performance.


2:Advanced Forming Processes: We master various technologies such as injection molding,
dry pressing, and isostatic pressing. We select the optimal solution based on the complexity
and precision requirements of your part to achieve one-time precision molding of complex
irregular structures.

3:Full-Size Precision Machining: Sintered blanks can be precisely ground, drilled, and polished
using diamond tools. We guarantee a machining tolerance of ±0.02mm and a surface finish up
to a mirror effect, ensuring a perfect fit for your equipment.

Advantage:Extraordinary Advantages from Material Science

1:Extreme Hardness & Wear Resistance: Zirconia ceramic's Vickers hardness (HV) can reach

over 1250, with wear resistance far exceeding that of alumina ceramics and most metals,

capable of withstanding long-term particle erosion and friction.

2:Excellent Mechanical Strength & Toughness: Benefiting from the "phase transformation

toughening" effect, our zirconia components possess high flexural strength and fracture

toughness, can withstand high loads and certain impacts, and avoid brittle fracture.

3:Powerful Chemical Corrosion Resistance: Highly inert to most acids, alkalis, solvents,
and molten metals, can operate stably in highly corrosive media for long periods, with a
lifespan far exceeding that of stainless steel.

4:Excellent Biocompatibility & Insulation: The material is safe and non-toxic, suitable for
biomedical applications; it is also an excellent insulator, ideal for electronics and electrical fields.

Product packaging

1:Individually packed in anti-static foam2:Vacuum-sealed for moisture protection
3:Labeled with part number, dimensions, and material grade
4:Shock-resistant outer packaging
5:Available in bulk or custom packaging




			Hunan Yuanhong New Material Co.,Ltd was established in 2016 ,there are over 100 sets of ceramic professional equipments , several types of furnace in more than 8000 square meters production workshops. ISO9001 certified, a variety of advanced ceramic materials are ROHS and REACH certified.


FAQ
Q1. Do you provide product samples?
Yes, we provide samples subject to availability. A nominal sample fee may apply in some cases, and shipping costs are borne by the customer.

Q2. What are your accepted payment methods?
We accept T/T (bank transfer) in advance, Western Union, Alipay, and PayPal.

Q3. What is your typical delivery lead time?
Lead times vary depending on product requirements, including material selection, dimensions, and specific manufacturing processes.

Q4. Do you perform quality inspection before shipment?
Yes, we conduct 100% inspection of all goods prior to delivery to ensure they meet specified standards.

Q5. What other ceramic materials do you offer?
We supply a range of advanced ceramic materials, including Alumina, Zirconia, Aluminum Nitride,Boron Nitride, Silicon Nitride, Machinable Glass Ceramic, and related specialized ceramics.
